High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
  • High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
  • High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
  • High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
  • High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
  • High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
  • High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300
High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300

High Speed & Programmable Mixer & Dispenser with Water Cooling Function for Dry Electrode Battery (Max. 10K rpm, 150 mL) - MSK-SFM-D300

SKU: high-speed-dispenser-max-10000-rpm-150-ml-for-slurry-mixing-msk-sfm-d300

Price: RFQ

Specifications

 MSK-SFM-D300 is a high-speed (Max. 10000 rpm) dispenser with a water cold tank volume of Max. 150 mL with a touch screen programmable controller to make a homogeneous slurry for battery, electrolyte/fuel cell, or other application fields. SPECIFICATIONS: Power Supply AC220V±10%, Single Phase, 50/60Hz, 600 W AC110V is available upon request Dispensing Speed Max. 10000 rpm (adjustable) Dispensing Time 1-30 min (adjustable) Control Panel Mixer is programmable via touchscreen controller Three-segment programs can be set for  various speeds and mixing times, and rest times Processing Volume Max. 150 mL Water Cooling Machine As low as <10 ℃ with circulated coolant from an optional water chiller. Please click the link below to order Dimension/Weight L300*W255*H440mm ~15.6 kg Certification CE Certified NRTL or CSA certification is available upon request at the extra cost.

Power Supply
  • AC220V±10%, Single Phase, 50/60Hz, 600 W
  • AC110V is available upon request
Dispensing Speed
  • Max. 10000 rpm (adjustable)
Dispensing Time
  • 1-30 min (adjustable)
 Control Panel
  • Mixer is programmable via touchscreen controller
  • Three-segment programs can be set for  various speeds and mixing times, and rest times

Processing Volume
  • Max. 150 mL
Water Cooling Machine
  • As low as <10 ℃ with circulated coolant from an optional water chiller. Please click the link below to order
Dimension/Weight
  • L300*W255*H440mm
  • ~15.6 kg
Certification
  • CE Certified
  • NRTL or CSA certification is available upon request at the extra cost.
