Continuous Rolling Press with 6 Stations and 5 Induction Heaters - MSK-1220-6S
  • Continuous Rolling Press with 6 Stations and 5 Induction Heaters - MSK-1220-6S
  • Continuous Rolling Press with 6 Stations and 5 Induction Heaters - MSK-1220-6S
  • Continuous Rolling Press with 6 Stations and 5 Induction Heaters - MSK-1220-6S
Continuous Rolling Press with 6 Stations and 5 Induction Heaters - MSK-1220-6S

Continuous Rolling Press with 6 Stations and 5 Induction Heaters - MSK-1220-6S

SKU: msk-1220-6s

Price: RFQ

Specifications

 MSK-1220-6S is a continuous rolling system with 6 rolling presses and 5 induction heaters, which is designed for preparing metallic tapes via powder in the tubing. SPECIFICATIONS: Power 208- 240V Three Phase, 50/60Hz Rolling Machine: 6 x 5.5 KW , 33KW required Induction heater5x10 KW, 50KW Total: 83KW , ( 100KW power panel required ) Rollers Six independent rolling press Roller materials: Hardening DC53 Roller size: 120 mm dia x 200 mm width Hardness: HRC 60-62 Rolling thickness: 0.08 - 13 mm adjustable Effective rolling width: 180 mm Rolling Speed: 0 - 6 mm/second adjustable by frequency variation controller The quartz guide plates of 100 mm width are placed between the rolling machine to guide the rolled strip from one machine to other Note: The roller has no Cr coating automatic lubricant oil adding is built-in Induction heater 5 independent induction heaters with the coil are placed between 6 rolling machines Induction frequency: 80K - 250K Hz 5 copper coils with 300 mm length are included and are placed between rolling pressed for annealing Output power is adjustable manually Each induction heater requires a 16 liter/minute water chiller , which is not included. Please click underlined to order or use your own lab cooling water system. Compliance CE Certified NRTL certification is available upon request at an extra cost.

Power
  • 208- 240V Three Phase, 50/60Hz
  • Rolling Machine: 6 x 5.5 KW , 33KW required
  • Induction heater5x10 KW, 50KW
  • Total: 83KW , ( 100KW power panel required )
Rollers
  • Six independent rolling press
    • Roller materials: Hardening DC53
    • Roller size: 120 mm dia x 200 mm width
    • Hardness: HRC 60-62
    • Rolling thickness: 0.08 - 13 mm adjustable
    • Effective rolling width: 180 mm
    • Rolling Speed: 0 - 6 mm/second adjustable by frequency variation controller
  • The quartz guide plates of 100 mm width are placed between the rolling machine to guide the rolled strip from one machine to other
  • Note: The roller has no Cr coating automatic lubricant oil adding is built-in
 Induction heater
  • 5 independent induction heaters with the coil are placed between 6 rolling machines
  • Induction frequency: 80K - 250K Hz
  • 5 copper coils with 300 mm length are included and are placed between rolling pressed for annealing
  • Output power is adjustable manually
  • Each induction heater requires a 16 liter/minute water chiller, which is not included. Please click underlined to order or use your own lab cooling water system.
Compliance
  • CE Certified
  • NRTL certification is available upon request at an extra cost.
