Automatic 6-channel Powder Dispensing System - AM-PD6
  • Automatic 6-channel Powder Dispensing System - AM-PD6
  • Automatic 6-channel Powder Dispensing System - AM-PD6
  • Automatic 6-channel Powder Dispensing System - AM-PD6
  • Automatic 6-channel Powder Dispensing System - AM-PD6
Automatic 6-channel Powder Dispensing System - AM-PD6

Automatic 6-channel Powder Dispensing System - AM-PD6

SKU: am-pd6

Price: RFQ

Specifications

 AM-PD6 is an automated powder dispensing system for high-throughput and autonomous experiments in condensed phase. This compact, glovebox-friendly unit is programmable via an LCD touchscreen and compatible with various types of powder in a fast and accurate manner up to 100 g ± 1 mg. The modular design can be used solely for 6 samples per batch or pairs with automated MTI materials preparation system for autonomous experiments. The free software advances instrumental communication, data acquisition, and logging in to a database. SPECIFICATIONS Power 208~240VAC, 50/60Hz, 3 kW Material Feeding System Six (6) 500 ml raw material containers with mechanical stirring Six (6) glass material feeder Feeding Capacity up to 100g Feeding Resolution 0.1 mg Feeding Accuracy 1 mg Note: accuracy may vary upon particle sizes, powder aggregation, Sample Holder Plastic tray with six (6) 30 ml plastic containers Process Program compositions for each sample. Place the sample tray with 6 empty plastic container X-Y stage moves individual sample for powder dispensing Once finished per batch, a notification will be sent. Compliance CE certified NRTL or CSA certification is available upon request at an extra cost of $3500.00 Optional A 16-channel and 36-channel automatic solid powder dosing system are available upon request.

Power
  • 208~240VAC, 50/60Hz, 3 kW
Material Feeding System
  • Six (6) 500 ml raw material containers with mechanical stirring
  • Six (6) glass material feeder
Feeding Capacity
  • up to 100g
Feeding Resolution
  • 0.1 mg
Feeding Accuracy
  • 1 mg
  • Note: accuracy may vary upon particle sizes, powder aggregation,
Sample Holder
  • Plastic tray with six (6) 30 ml plastic containers
Process
  • Program compositions for each sample.
  • Place the sample tray with 6 empty plastic container
  • X-Y stage moves individual sample for powder dispensing
  • Once finished per batch, a notification will be sent.
Compliance
  • CE certified
  • NRTL or CSA certification is available upon request at an extra cost of $3500.00
Optional A 16-channel and 36-channel automatic solid powder dosing system are available upon request.
