5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E
  • 5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E
  • 5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E
  • 5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E
  • 5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E
  • 5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E
5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E

5L Slurry Feeder with Peristaltic Pump for R2R Blade & Microgravure Coating-MSK-156-E

SKU: msk-156-e

Price: RFQ

Specifications

 MSK-156-E is an automatic slurry feeder with a peristalic pump and stainless steel reservoir. It is designed for use with MTI Roll-to-Roll web coating system MSK-AFA-DS300 , MSK-AFA-200 or MSK-AFA-MC200-LD for the Li-ion battery electrode coating process. Features Peristalic pump for various low-to-high viscosity slurry feeding. Pneumatic airtight slurry reservoir. Corrosion-resistant pipeline compatible with mild acidic and alkaline slurries Power Requirement AC 220V +/- 10% Single phase 500W Max. Compressed Gas Requirement 0.5~0.8MPa compress gas is required. Feeding rate 0.001 to 720 mL/min, adjustable Feeding Rotation Speed: 0.1-150 r/min Slurry Reservoir 5L effective volume, 304 stainless steel NMP Compatible It is compatible with NMP Warranty One-Year limited warranty with lifetime support Rusting and damage due to improper storage condition or maintenance are not covered by warranty Application Note This slurry feeder is meant to be used with roll-to-roll web coaters MSK-AFA-DS300, MSK-AFA-200 or MSK-AFA-MC200-LD. Please contact us to check its compatibility with other products. Please click pic 1 below to see the vacuum mixing for roll to roll coating flow chart

Features
  • Peristalic pump for various low-to-high viscosity slurry feeding.
  • Pneumatic airtight slurry reservoir.
  • Corrosion-resistant pipeline compatible with mild acidic and alkaline slurries

Power Requirement
  • AC 220V +/- 10% Single phase
  • 500W Max.

Compressed Gas Requirement
  • 0.5~0.8MPa compress gas is required.

Feeding rate
  • 0.001 to 720 mL/min, adjustable
  • Feeding Rotation Speed: 0.1-150 r/min

Slurry Reservoir
  • 5L effective volume, 304 stainless steel

NMP Compatible
  • It is compatible with NMP

Warranty
  • One-Year limited warranty with lifetime support
  • Rusting and damage due to improper storage condition or maintenance are not covered by warranty

Application Note

 This slurry feeder is meant to be used with roll-to-roll web coaters MSK-AFA-DS300, MSK-AFA-200 or MSK-AFA-MC200-LD.
Please contact us to check its compatibility with other products.
Please click pic 1 below to see the vacuum mixing for roll to roll coating flow chart
