50 Cavities Vortex Vibration Ball Mill w/ YSZ Balls for High-Throughput Research - MSK-SFM-50
  • 50 Cavities Vortex Vibration Ball Mill w/ YSZ Balls for High-Throughput Research - MSK-SFM-50
  • 50 Cavities Vortex Vibration Ball Mill w/ YSZ Balls for High-Throughput Research - MSK-SFM-50
  • 50 Cavities Vortex Vibration Ball Mill w/ YSZ Balls for High-Throughput Research - MSK-SFM-50
50 Cavities Vortex Vibration Ball Mill w/ YSZ Balls for High-Throughput Research - MSK-SFM-50

50 Cavities Vortex Vibration Ball Mill w/ YSZ Balls for High-Throughput Research - MSK-SFM-50

SKU: msk-sfm-50

Price: RFQ

Specifications

 MSK-SFM-50 is a high throughput vortex-vibration ball mill that sets the performance standard for small quantity milling and mixing up to 50 samples for 15 ml tube, which takes place (often within 60 seconds) inside the disposable 5 ml screw-cap microtubes. The optimized mixing motion causes rapid milling through constant high-velocity impact from the hardened YSZ micro-beads. It is excellent for material genome initiative research of ceramic compounds. SPECIFICATIONS: Working Voltage 100 - 240V AC 50/60Hz for worldwide use 60W ( 1.5A ) US Plug LCD Control LCD controller for setting speed and time Speed range: 500-2500rpm Cycle Time: 1min - 99h59min, or 1sec - 99min59sec Max. Loading Capacity 4.5 Kg Max. Sample Holder & Tube Standard plastic foam sample holder for 50 pcs 16 mm Dia x 115 mm L nylon tube 50 pcs Nylon tubes ( 16mm dia.,~15 ml) are included for immediate use A spare sample holder with a cavity of various size is available upon request at an extra cost Tube Holder Holder P/N Tube Qty & Diameter Tube Holder Size(mm) MTV-B01 50x Ø10mm 245x132x45 MTV-B02 50x Ø12mm 245x132x45 MTV-B04 50x Ø16mm 245x132x45 MTV-B05 15x Ø25mm 245x132x45 MTV-B06 15x Ø29mm 245x132x45 MTV-B00 Spare holder 305x178.5x25 Optional containers Click here to see a video This vibrating device also can clamp single or multiple containers for mixing and milling. Click Pic. 1-2 to order a container Pic. 1                  Pic. 2

Working Voltage
  • 100 - 240V AC 50/60Hz for worldwide use
  • 60W ( 1.5A )
  • US Plug
LCD Control
  • LCD controller for setting speed and time
    • Speed range: 500-2500rpm
    • Cycle Time: 1min - 99h59min, or 1sec - 99min59sec
Max. Loading Capacity
  •  4.5 Kg Max.
Sample Holder & Tube
  • Standard plastic foam sample holder for 50 pcs 16 mm Dia x 115 mm L nylon tube
  • 50 pcs Nylon tubes ( 16mm dia.,~15 ml) are includedfor immediate use
  • A spare sample holder with a cavity of various size is available upon request at an extra cost
  • Tube Holder Holder P/N Tube Qty & Diameter Tube Holder Size(mm)
    MTV-B01 50x Ø10mm 245x132x45
    MTV-B02 50x Ø12mm 245x132x45
    MTV-B04 50x Ø16mm 245x132x45
    MTV-B05 15x Ø25mm 245x132x45
    MTV-B06 15x Ø29mm 245x132x45
    MTV-B00 Spare holder 305x178.5x25
Optional containers

Click here to see a video
  • This vibrating device also can clamp single or multiple containers for mixing and milling. Click Pic. 1-2 to order a container
         Pic. 1                  Pic. 2
,
Tube Holder Holder P/N Tube Qty & Diameter Tube Holder Size(mm)
MTV-B01 50x Ø10mm 245x132x45
MTV-B02 50x Ø12mm 245x132x45
MTV-B04 50x Ø16mm 245x132x45
MTV-B05 15x Ø25mm 245x132x45
MTV-B06 15x Ø29mm 245x132x45
MTV-B00 Spare holder 305x178.5x25
